Ariel's large medium-speed reciprocating separable compressors are designed to pair with electric motors and natural gas engines. These compressors are engineered for applications requiring large horsepower drivers and high-compression capacity.
El arte de permitir libro pdf love. The leader knew that France would be better off if their country was on favorable terms with Germany, so somehow he encouraged the people of France to appreciate the Germans more, which was hard, after 2 terrible wars.
A frame-driven lube oil pump provides cooled oil through a full-flow oil filter to all moving parts in the frame. A divider-block system supplies metered oil to cylinder bores and rod packings.
Durable Grade 8 bolting on all loaded joints combined with specially designed fatigue-fighting bolts on all valve caps ensure ultimate holding strength.
The JGC/JGD/JGF compressors feature durable connecting rods manufactured from forged steel with 4 bolts and a heavy-duty “I” section.
One-piece, long-life crossheads with hardened, ground steel crosshead pins and direct, full-pressure lubrication at the top and bottom for minimum wear.
Ariel’s single and double-acting non-cooled cylinders eliminate the cost and maintenance associated with water cooling.
JGC/JGD/JGF compressors feature wear-resistant ductile or gray iron pistons and precision-ground alloy steel piston rods with locking crosshead nuts. Rolled threads are 1/4” under rod diameter for easy installation.
Every Ariel compressor features precision-machined tri-metal main and connecting rod bearings.
Ariel offers manual, head-end variable volume clearance pockets on most cylinders. Pneumatic suction valve unloaders are available on a limited basis.
Plate-type valves are designed for modern speeds, utilizing nonmetallic sealing elements as standard. Valves are selected to comply with established low-valve velocity standards.
The JGC/JGD/JGF compressors feature forged steel, precision-machined crankshafts with integral counter-weights manufactured by Ariel Corporation.
Ariel JGC/JGD/JGF compressors feature high-efficiency canister type oil filters rated at 1 micron nominal and 12 micron absolute.
Ariel crankcases are designed for long service life and ease of access during maintenance. Our crankcases feature a heavily-ribbed, high-strength cast iron base with a removable lightweight aluminum top cover.
| JGC | JGD | JGF | |
|---|---|---|---|
| Number of Throws | 4 | 4 | 4 |
| Rated Power (BHP) | 4,410 | 4,410 | 4,410 |
| Rated Power (kW) | 3,087 | 3,087 | 3,087 |
| Stroke (in) | 6.5 | 5.5 | 5.0 |
| Stroke (mm) | 165 | 140 | 127 |
| Maximum RPM | 1,000 | 1,200 | 1,400 |
| Piston Speed (FPM) | 1,083 | 1,100 | 1,167 |
| Piston Speed (m/s) | 5.5 | 5.59 | 5.9 |
| Total Rod Load (lbs) | 114,000 | 114,000 | 114,000 |
| Total Rod Load (N) | 506,097 | 506,097 | 506,097 |
| Rod Load Tension (lbs) | 57,000 | 57,000 | 57,000 |
| Rod Load Tension (N) | 253,549 | 253,549 | 253,549 |
| Rod Load Compression (lbs) | 60,000 | 60,000 | 60,000 |
| Rod Load Compression (N) | 266,893 | 266,893 | 266,893 |
| Rod Diameter (in) | 2.50 | 2.50 | 2.50 |
| Rod Diameter (mm) | 64 | 64 | 64 |
| Crankshaft Centerline from bottom (in) | 22 | 22 | 22 |
| Crankshaft Centerline from bottom (mm) | 559 | 559 | 559 |
